Strong and wide rib help offer outstanding stability and excellent traction
Special designed for terminal tractors
Static free compound
| Tire Size | Type | LI/SS | Star Rating | TRA Code or Application | Recommended Rim/Flange Height | Approximate Inflated Dimensions | OTD | Cold Inflation Pressure | Max. Load Capacity | Application Max.Speed | |||||||||
| OD | SW | SLR | |||||||||||||||||
| inch | mm | inch | mm | inch | mm | inch | mm | 32ND | KPa | Psi | Kg | Lbs | km/h | mph | |||||
| 280/75R22.5 | TL | 168A8 | - | TERMINAL | 8.25 | 992 | 39.1 | 280 | 11.0 | - | - | 32 | 40 | 1000 | 145 | 5600 | 12300 | 40 | 25 |
| 300/80R22.5 | TL | 172A8 | - | TERMINAL | 9.00 | 1052 | 41.4 | 301 | 11.9 | - | - | 18 | 23 | 1000 | 145 | 6300 | 13900 | 40 | 25 |
| 310/80R22.5 | TL | 175A8 | - | TERMINAL | 9.00 | 1078 | 42.4 | 300 | 11.8 | - | - | 32 | 40 | 1000 | 145 | 6900 | 15200 | 40 | 25 |
*Reserves the rights of final interpretation and modification
