Large tread pattern designed for long tire life and optimized cost per hour
Reinforced crown and sidewalls for limited downtime
All steel radial structure reduce heat building up comparing to bias structure
| Tire Size | Type | LI/SS | Star Rating | TRA Code or Application | Recommended Rim/Flange Height | Approximate Inflated Dimensions | OTD | Cold Inflation Pressure | Max. Load Capacity | Application Max.Speed | |||||||||
| OD | SW | SLR | |||||||||||||||||
| inch | mm | inch | mm | inch | mm | inch | mm | 32ND | KPa | Psi | Kg | Lbs | km/h | mph | |||||
| 10R16.5 | TL | 129A8 | - | - | 8.25 | 773 | 30.4 | 267 | 10.5 | 358 | 14.1 | 19 | 24 | 500 | 73 | 1850 | 4080 | 40 | 25 |
| 12R16.5 | TL | 137A8 | - | - | 9.75 | 831 | 32.7 | 305 | 12.0 | 383 | 15.1 | 23 | 29 | 500 | 73 | 2300 | 5080 | 40 | 25 |
| 12R16.5 | TL | 141A5 | - | - | 9.75 | 831 | 32.7 | 305 | 12.0 | 383 | 15.1 | 23 | 29 | 375 | 54 | 2575 | 5680 | 25 | 15 |
*Reserves the rights of final interpretation and modification
