Specially designed non-directional tread pattern offers extra gripping power
Longer tread life due to the deeper tread depth and unique tread compound
New sidewalls are shaped to minimize damage from cutting
Optimised Retreading Ability because of the robust casing
New model to replace CB760
| Tire Size | Type | LI/SS | Star Rating | TRA Code or Application | Recommended Rim/Flange Height | Approximate Inflated Dimensions | OTD | Cold Inflation Pressure | Max. Load Capacity | Application Max.Speed | |||||||||
| OD | SW | SLR | |||||||||||||||||
| inch | mm | inch | mm | inch | mm | inch | mm | 32ND | KPa | Psi | Kg | Lbs | km/h | mph | |||||
| 17.5R25 | TT/TL | 167B | ★★ | E-3 | 14.00/1.5 | 1350 | 53.1 | 445 | 17.5 | 618 | 24.3 | 29 | 37 | 525 | 76 | 5450 | 12000 | 50 | 30 |
| 17.5R25 | TT/TL | 182A2 | ★★ | L-3 | 14.00/1.5 | 1350 | 53.1 | 445 | 17.5 | 618 | 24.3 | 29 | 37 | 650 | 94 | 8500 | 18700 | 10 | 5 |
| 20.5R25 | TT/TL | 177B | ★★ | E-3 | 17.00/2.0 | 1490 | 58.7 | 520 | 20.5 | 677 | 26.7 | 31 | 39 | 525 | 76 | 7300 | 16100 | 50 | 30 |
| 20.5R25 | TT/TL | 193A2 | ★★ | L-3 | 17.00/2.0 | 1490 | 58.7 | 520 | 20.5 | 677 | 26.7 | 31 | 39 | 650 | 94 | 11500 | 25400 | 10 | 5 |
| 23.5R25 | TT/TL | 185B | ★★ | E-3 | 19.50/2.5 | 1615 | 63.6 | 595 | 23.4 | 730 | 28.7 | 38 | 48 | 525 | 76 | 9250 | 20400 | 50 | 30 |
| 23.5R25 | TT/TL | 201A2 | ★★ | L-3 | 19.50/2.5 | 1615 | 63.6 | 595 | 23.4 | 730 | 28.7 | 38 | 48 | 650 | 94 | 14500 | 32000 | 10 | 5 |
*Reserves the rights of final interpretation and modification
